12.8V 42-60Ah SOLAR LIGHTING BATTERY PACK
High-capacity solar lighting battery delivering 537.6Wh to 768Wh of energy. Designed for high-power solar street lights (60-100W), commercial area lighting, solar floodlights, and large outdoor installations. Available in 42Ah, 48Ah, 50Ah, and 60Ah configurations with IP65 enclosure.
Key Features & Benefits
- LiFePO4 Chemistry — 4S Configuration, 12.8V Nominal
- Multiple Capacities Available (42 / 48 / 50 / 60Ah)
- High Discharge Rate — Up to 60A (1C) Continuous
- Suitable for All-Night Operation
- IP65 Weatherproof Enclosure
- Built-in BMS Protection (OVP, UVP, OCP, OTP)
- Lightweight Design — 4.2 to 6.0kg
- Zero Maintenance, Silent Operation
Product Description
The PowerPulse 12.8V 42-60Ah Solar Lighting Battery Pack is a high-power LiFePO4 solution engineered specifically for demanding solar street lighting, commercial area lighting, solar floodlights, and large outdoor solar lighting installations. With configurable capacities ranging from 42Ah to 60Ah, it provides between 537.6Wh and 768Wh of usable energy — enough to power high-wattage LED fixtures throughout the entire night.
Built on a proven 4S LiFePO4 cell configuration, this battery supports discharge currents up to 1C (42-60A), making it ideal for 60-100W solar street light heads. The rugged IP65-rated enclosure ensures reliable performance in outdoor environments exposed to dust, rain, and humidity. Available in four standard capacity options — 42Ah, 48Ah, 50Ah, and 60Ah — to match diverse project specifications and lighting load requirements.
The integrated Battery Management System (BMS) provides comprehensive protection against overcharge, over-discharge, overcurrent, and thermal faults, ensuring long service life and safe operation across thousands of charge-discharge cycles.
Technical Specifications
| Parameter | Specification |
|---|---|
| Nominal Voltage | 12.8V |
| Cell Chemistry | LiFePO4 (4S Configuration) |
| Capacity Options | 42Ah / 48Ah / 50Ah / 60Ah (Configurable) |
| Energy Range | 537.6Wh (42Ah) to 768Wh (60Ah) |
| Charge Voltage | 14.6V |
| Discharge Cut-off Voltage | 10.0V |
| Max Discharge Current | 42-60A (1C, capacity dependent) |
| Cycle Life | 4000+ Cycles @ 80% DOD |
| Round-Trip Efficiency | >95% |
| Operating Temperature | 0°C to 50°C |
| Weight | ~4.2 kg (42Ah) to ~6.0 kg (60Ah) |
| Dimensions | ~260 × 75 × 130 mm |
| Enclosure Rating | IP65 |
| BMS Protection | OVP, UVP, OCP, OTP, Short Circuit |
| Communication | RS485 / Bluetooth (Optional) |
Additional Information
- Ideal for high-power solar street lights (60-100W)
- Suitable for commercial area lighting and solar floodlights
- Designed for all-night continuous operation
- Compatible with 12V solar charge controllers and LED drivers
- Multiple capacity options (42 / 48 / 50 / 60Ah) for flexible project sizing
- IP65 enclosure for outdoor weatherproof installation
- Direct replacement for sealed lead-acid (SLA) batteries
- Expandable in parallel configurations
- Zero maintenance and silent operation
- Built-in BMS with full cell-level protection
